18350 Li-ion 1600mAh Battery Highest Capacity Flat Top Unprotected Rechargeable Cell

🆕 18350 Battery Li-ion Rechargeable 1600mAh Flat Top Unprotected

Upgrade your power source with the next-generation ORB18350-16 Orbtronic Li-ion battery. Engineered for demanding applications, this high-capacity 18350 cell delivers 1600mAh of reliable energy in a compact form factor. Featuring a flat top positive terminal and enhanced discharge runtime, it’s the ideal choice for flashlights, weapon lights, and custom electronics requiring maximum runtime and performance.

💡 Key Features & Benefits

• Highest capacity available in 18350 format: 1600mAh
• Flat top terminal for secure contact and compatibility
• Supports up to 8A pulse discharge for high-drain devices
• Improved cycle life: 500 charge/discharge cycles
• Compact size with powerful energy density
• Next-gen upgrade from Orbtronic 1200mAh model

🔧 Core Specifications

• Model Name: ORB18350-16
• Battery Type: 18350 Rechargeable Lithium-ion Battery Cell
• Nominal Voltage: 3.6V-3.7V
• Rated Capacity: 1600mAh
• Nominal Capacity: ≥ 1550mAh
• Nominal Energy: 5920 mWh
• Internal Impedance: ≤ 50mΩ
• Cycle Life: 500 charging / discharging cycles

⚡ Charging Specifications

• Charging Method: Constant Current - Constant Voltage (CC-CV)
• Charging Voltage: 4.2V
• Recommended Charging Current: 300mA-500mA
• Cut-off Current: 48mA (0.03C)
• Maximum Charging Current: 1120mA (0.7C)
• Charging Temperature Range: 0°C to +45°C (32°F to 113°F)

🔋 Discharging Specifications

• Max Continuous Discharging Current: 5A
• Maximum Discharging Current (Pulse): 8A
• Recommended Pulse Profile: ≤ 5 sec ON / ≥ 30 sec OFF
• Load Termination: Terminate load at cell temperature reaching 65°C (149°F)
• Discharging Temperature Range: -20°C to +60°C (-4°F to 140°F)
• Capacity Retention at Various Temperatures:
  -20°C (-4°F): ≥ 72%
  0°C (32°F): ≥ 82%
  +25°C (77°F): 100%
  +60°C (140°F): ≥ 98%

📊 Dimensions & Weight

• Diameter (with jacket): 18.4mm (+0.1 / -0.3mm) ≈ 0.724in
• Height (with jacket): 35.0mm (+0.2 / -0.3mm) ≈ 1.378in
• Weight: ≤ 25g (0.88oz)

❄ Storage Conditions

• 1 Month: -20°C to +50°C (-4°F to 122°F)
• 3 Months: -20°C to +40°C (-4°F to 104°F)
• 1 Year: -20°C to +25°C (-4°F to 77°F)

📦 What’s in the Box

• 1 × ORB18350-16 Orbtronic rechargeable Li-ion battery cell
• 1 × Safety storage carrying case (holds up to 2 cells)
• Note: Price listed is for one battery cell

🚚 Shipping Info

• Same business day shipping from Florida USA
• Orders placed by 3PM EST ship out the same day
• Fast and secure packaging for safe delivery

⚠️ Safety & Handling

Important: For Experienced Users Only
This high-performance Li-ion cell is unprotected and intended for use only in devices with built-in safety systems (BMS or equivalent). Not for use in vape, e-cigarette, or similar devices.

Battery Safety Guidelines
Improper use may result in fire, injury, or damage. Always follow these precautions:

• Use only a Li-ion charger rated for 4.2V CC/CV charging
• Charge fully before first use. Never charge unattended
• Do not short-circuit, reverse polarity, or exceed rated current
• Do not expose to heat, water, or direct sunlight
• Do not disassemble, modify, or solder directly onto the cell
• Store in a protective case-never loose in pockets or bags
• Inspect before each use. Stop using if wrap or insulator is damaged
• Do not mix old and new cells. Do not force installation
• Discontinue use if cell emits odor, heat, or changes shape
• Keep away from children and pets

Short Circuit Risk
Unprotected cells discharge rapidly if terminals are bridged. This can cause extreme heat and damage. Always use with proper safeguards.

User Responsibility Agreement
By purchasing, you confirm technical knowledge of Li-ion safety and accept full responsibility for proper handling, charging, and use. Orbtronic is not liable for misuse or device incompatibility. If unsure, contact us 24/7-we’re here to help.
